G140
INSTRUMENTS/CONTROLS 4. The following LED’s indicators do not activate the audible warning: • Parking brake, D;
5. Differential lock functions only with the parking brake disengaged and only in 1st to 7th gears. 6. Q - Speedometer registers the travel speed.
• Steering secondary (optional), P;
R - Indicates the engine RPM during operation.
• Differential lock, T;
S - Not available.
• General warning light, L; • High beam, N; • Turn signals, O and M.
INSTRUMENT PANEL INDICATORS A. ENGINE WATER TEMPERATURE
E. LOW BATTERY CHARGE
When the light is ON, it means that the engine coolant has overheated which could be caused by:
When this light is ON, with the engine running, indicates defects in the charging system, caused by:
•
Lack of coolant in the system
•
Defective alternator
•
Radiator cooling fins clogged
•
Charging resistor damaged
•
Radiator circuit clogged
F. LOW TRANSMISSION OIL PRESSURE
•
Fan hydraulic drive system malfunction
•
Defective thermostat.
When the light is ON, this indicates insufficient oil pressure that may be caused by:
B. HYDRAULIC OIL TEMPERATURE
•
Use of oil with improper viscosity
When the light is ON, it means that the oil is overheated which could be caused by:
•
Low transmission oil level
•
Defective switch and/or defective panel.
•
Use of oil with improper viscosity
G. LOW ENGINE OIL PRESSURE
•
Low oil level.
When the light is ON, this indicates insufficient oil pressure that may be caused by:
C. TRANSMISSION OIL TEMPERATURE When the light is ON, it means that the oil is overheated and its probable causes are:
•
Use of oil with improper viscosity
•
Low engine oil level
•
Suction line filter clogged
•
Engine oil leak
•
Low oil level
•
Defective pressure switch
•
High oil level
•
Transmission hydraulic oil circuit troubles.
D. PARKING BRAKE When the light is ON, it means that the brake is actuated.
Read the SAFETY RULES on the preceding pages for machine protection and the safety of employees
