OPERATING INSTRUCTIONS F106.6 / F106.6A / F156.6 / F156.6A Clutch-codes Code
40001345.00-de
Definition
4209
red
Short circuit to battery voltage at clutch K1
4210
red
Short circuit to ground at clutch K1
4211
red
Open circuit at clutch K1
4212
red
Short circuit to battery voltage at clutch K2
4213
red
Short circuit to ground at clutch K2
4214
red
Open circuit at clutch K2
4215
red
Short circuit to battery voltage at clutch K3
4216
red
Short circuit to ground at clutch K3
4217
red
Open circuit at clutch K3
4225
red
Short circuit to battery voltage at clutch K4
4226
red
Short circuit to ground at clutch K4
4227
red
Open circuit at clutch K4
4228
red
Short circuit to battery voltage at clutch KV
4229
red
Short circuit to ground at clutch KV
4230
red
Open circuit at clutch KV
4231
red
Short circuit to battery voltage at clutch KR
4232
red
Short circuit to ground at clutch KR
4233
red
Open circuit at clutch KR
4241
red
Short circuit to ground at backup alarm relay
4242
red
Short circuit to battery voltage at backup alarm relay
4243
red
Open circuit at backup alarm relay
Possible Steps for repair 1. Check the cable from the TCU to the transmission control valve. 2. 2.Check the connectors from the TCU to the transmission control valve. 3. 3.Check the regulator resistance. 4. Check internal wire harness of the transmission control valve
1. 1.Check the cable from the TCU to the backup. alarm relay. 2. Check the connectors from the backup alarm relay to TCU. 3. Check the resistance of backup alarm relay circuit. Î
