OPERATING INSTRUCTIONS F106.6 / F106.6A / F156.6 / F156.6A Front blade (option)
40001307.00-en
The front blade is raised and lowered with control lever (71, Fig. 4)
The position of the front blade is indicated by a pointer (Fig. 6).
Position 9 = lowering the front blade
Position 1 = blade completely raised
Position 10 = raising the front blade
Position 2 = for road travel (yellow) Position 3 = blade resting on the ground Position 4 = max. scraping depth
Fig. 4
The shut-off valve (Fig. 5) must be open, i.e. the lever must be in position 1.
Fig. 6
Fig. 5
107
