OPERATING INSTRUCTIONS F106.6 / F106.6A / F156.6 / F156.6A Wheel rake The wheel rake can be hydraulically adjusted (Fig. 9) with control lever (72, Fig. 10): Position 19 =
adjust wheel rake to the left
Stellung 20 =
adjust wheel rake to the right.
Fig. 9
Fig. 10
The wheel rake adjustment: • reduces the machine's turning circle, • compensates lateral thrust during scraping, • gives better grip on the ground. If the wheel rake is adjusted when the steering is at either of the limit stops, the steering wheel turns back by a slight amount.
100
