7.5.2
Injector – Removal and installation Preconditions ☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts Designation / Use
Part No.
Qty.
Installation/removal tool
F6789889
1
Milling cutter
F30452739
1
Torque wrench, 0.5-5 Nm
0015384230
1
Torque wrench, 10-60 Nm
F30452769
1
Ratchet
F30027340
1
Torque wrench, 60-320 Nm
F30452768
1
Ratchet
F30027341
1
40477
1
X00029933
1
Assembly paste (Optimoly Paste White T) Grease (Kluthe Hakuform 30-10/Emulgier) Engine oil O-ring WARNING
(→ Spare Parts Catalog)
Fuels are combustible. Risk of fire and explosion! • Avoid open flames, electrical sparks and ignition sources. • Do not smoke.
Preparatory steps 1. 2.
Shut off fuel supply to engine. Remove cylinder head cover (→ Page 143).
Removing injector Disconnect connectors on injector.
TIM-ID: 0000000925 - 010
1.
MS150036/02E 2013-11 | Task Description | 147
