6.13.2
Engine oil – Change Preconditions ☑Engine is stopped and starting disabled. ☑Engine is at operating temperature. ☑MTU Fluids and Lubricants Specifications (A001061/..) are available.
Special tools, Material, Spare parts Designation / Use
Part No.
Qty.
Torque wrench, 40-200 Nm
F30027337
1
Ratchet adapter
F30027341
1
Engine oil Sealing ring WARNING
(→ Spare Parts Catalog)
Hot oil. Oil can contain combustion residues which are harmful to health. Risk of injury and poisoning! • Wear protective clothing, gloves, and goggles / safety mask. • Avoid contact with skin. • Do not inhale oil vapor.
Oil change without semirotary hand pump: Draining oil via drain plug(s) on oil pan 1. 2. 3.
Provide a suitable container to collect the oil. Remove drain plug(s) and drain oil. Install drain plug(s) with new sealing ring.
Oil change with semirotary hand pump: Oil extraction 1. 2.
Provide a suitable container to collect the oil. Draw all oil from oil pan using the semirotary hand pump.
Draining residual oil at gearcase 1.
TIM-ID: 0000014099 - 003
2.
3.
Provide a suitable container to collect the oil. Remove drain plugs (1) and (2) and drain oil: • Approx. 12 liters at (1) • Approx. 5 liters at (2) Install drain plug(s) with new sealing ring.
MS150068/01E 2014-01 | Task Description | 219
