MTU 12V4000M23F_ 12V4000M23S_ 16V4000M23F_ 16V4000M23S_ MS150068_01E Diesel Engine Operating Instruc

6.7.6

Fuel prefilter – Draining Preconditions ☑Engine is stopped and starting disabled.

WARNING

Fuels are combustible. Risk of fire and explosion! • Avoid open flames, electrical sparks and ignition sources. • Do not smoke.

Draining fuel prefilter 1.

Cut out the filter to be replaced (A or B). 1 Filter A cut out 2 Filter B cut out

2. 3. 4.

Open vent plug (1) of filter to be drained. Open drain valve (2). Drain water and contaminants from filter until pure fuel emerges. Close drain cock (2).

TIM-ID: 0000018510 - 004

5.

MS150068/01E 2014-01 | Task Description | 191
