MTU 12V4000M23F_ 12V4000M23S_ 16V4000M23F_ 16V4000M23S_ MS150068_01E Diesel Engine Operating Instruc

6.6.2

Injector – Removal and installation Preconditions ☑Engine is stopped and starting disabled.

Special tools, Material, Spare parts Designation / Use

Part No.

Qty.

Installation/removal jig

F6789889

1

Milling cutter

F30452739

1

Torque wrench, 0.5-5 Nm

0015384230

1

Torque wrench, 10-60 Nm

F30452769

1

Ratchet adapter

F30027340

1

Torque wrench, 60-320 Nm

F30452768

1

Ratchet adapter

F30027341

1

40477

1

X00059351

1

Assembly paste(Optimoly Paste White T) Assembly compound (Kluthe Hakuform 30-11C/Emulgier) Engine oil O-ring WARNING

(→ Spare Parts Catalog)

Fuels are combustible.

Risk of fire and explosion!

• Avoid open flames, electrical sparks and ignition sources.

• Do not smoke.

Preparatory steps 1.

2.

Shut off fuel supply to engine.

Remove cylinder head cover (→ Page 176).

Removing injector Disconnect connectors on injector.

TIM-ID: 0000000925 - 012

1.

180 | Task Description | MS150068/01E 2014-01
