MTU 12V4000M23F_ 12V4000M23S_ 16V4000M23F_ 16V4000M23S_ MS150068_01E Diesel Engine Operating Instruc

6.4.2

Valve clearance – Check and adjustment Preconditions ☑Engine is stopped and starting disabled. ☑Engine coolant temperature is max. 40 °C. ☑Valves are closed.

Special tools, Material, Spare parts Designation / Use

Part No.

Qty.

Feeler gage

Y20010128

1

Torque wrench, 60-320 Nm

F30452768

1

Socket wrench, 24 mm

F30039526

1

Engine oil

Preparatory steps Remove cylinder head cover (→ Page 176). Install barring gear (→ Page 162).

3.

The OT mark (1) on the flywheel (if applicable) must not be used for reference.

TIM-ID: 0000012224 - 007

1. 2.

MS150068/01E 2014-01 | Task Description | 173
