19. INSTALLING BUCKET OR ATTACHMENT TO SKID STEER TOOL CARRIER IMPORTANT: Refer to Pages 62 to 63 for instructions concerning Skid Steer Tool Carrier Handles Disengaged and Engaged Positions. CAUTION: Before leaving the tractor seat, stop the engine and lock brakes when installing or removing bucket or attachment. CAUTION: Do not stand, walk, or work under a raised loader or attachment unless it is securely blocked or held in position. Accidental movement of valve handle/handles or leaks in the hydraulic system could cause the loader to drop, or attachment to dump, causing severe injury.
19.1. OPERATING INSTRUCTIONS 19.1.1. To attach bucket or attachment to loader, lower loader boom to ground with Skid Steer Tool Carrier attachment rolled forward slightly.
19.1.2. To position handles into the handle disengaged position, pull skid steer tool carrier handle upward. Pull Handles Upward
(1) Handles disengaged position.
19.1.3. Roll Skid Steer Tool Carrier attachment forward by extending tilt cylinders just enough to allow Skid Steer Tool Carrier upper vee to engage Skid Steer attachment vee channel. Drive tractor forward, aligning Skid Steer Tool Carrier vee components. Align Skid Steer Tool Carrier vee with Skid Steer Attachment vee channel. NOTE: Over extension of tilt cylinders during this operation could cause damage to Skid Steer Tool Carrier handles due to handles contacting bucket or attachment.
64
