1. SPECIFICATIONS Model ML170 Front End Loader U
For Use With Model 7010 Tractor
E
D A C
B
P J G
Y
H
F
SPECIFICATIONS OF LOADER: ..................................................................................................................... ML170 A. Maximum Lift Height to Pivot Pin ................................................................................................11’ 0" (132") B. Maximum Lift Height under Level Bucket................................................................................... 10’ 3" (123") C. Clearance with Bucket Fully Dumped ............................................................................... 8’ 6-1/2" (102.50") D. Reach at Maximum Lift Height (to Grill Guard) ................................................................... 2’ 8-3/4" (32.75") E. Maximum Dump Angle ................................................................................................................. 42 degrees F. Reach With Bucket on Ground....................................................................................................... 7' 2" (86") G. Maximum Rollback Angle............................................................................................................. 26 degrees H. Digging Depth........................................................................................................................................6-1/4" J. Overall Height in Carry Position ....................................................................................... 5’ 5-1/2"* (65.50"*) L. Bucket Depth........................................................................................................................................25.86" M. Bucket Height .......................................................................................................................................26.20" N. Loader Bucket Pin to Front of Front Cutting Edge ...............................................................................33.46" P. Loader Bucket Pin to Bottom of Front Cutting Edge ..............................................................................9.00" U. Lift Capacity to Maximum Height at Pivot Pin ................................................................................... 3300 lb. Y. Breakout Force at Ground Line at Pivot Pin...................................................................................... 5200 lb. *Top of Arm at Bucket Pivot Pin with Bucket 12" off ground.
CYCLE TIMES Raising Time Ground Line to Maximum Lift Height Lowering Time Maximum Lift Height to Ground Line Dumping Time Full Rollback to Full Dump without Regen Dumping Time Full Rollback to Full Dump with Regen Rollback Time Full Dump to Full Rollback
1000 RPM 1500 RPM 2000 RPM 2500 RPM 16.5 sec. ....... 11.5 sec..........7.9 sec.......... 7.2 sec. 9.6 sec. ......... 9.0 sec...........7.7 sec.......... 5.2 sec. 10.0 sec. ........ 7.8 sec...........5.4 sec.......... 4.5 sec. 6.3 sec. ......... 5.7 sec...........5.0 sec.......... 4.7 sec. 7.0 sec. ......... 5.6 sec...........3.5 sec.......... 3.1 sec.
Lift Cylinder Dia. .......................................................................................................................................................3" Tilt Cylinder Dia. .................................................................................................................................................2-1/2" Tire Sizes (specifications taken with) .................................................Front: 9.5Lx15 .......................... Rear: 16.9x28 Relief Valve Setting (Loader Valve) w/o Hyd. Self Level ............................................................................... 2600 psi Relief Valve Setting (Loader Valve) with Hyd. Self Level .............................................................................. 2600 psi Specifications taken with Mounting Kit, Hose Kit, and 78" Pin On Standard Bucket. Specifications based on ASAE standards S301.3 and furnished for general information only as they can vary with different tractor models. Specifications are subject to change without notice and without liability therefore.
1.1. ATTACHMENT SPECIFICATIONS BUCKET 78" Pin On Material
STRUCK CAPACITY 18.59 cu. ft.
14
RATED SIZE CAPACITY 22.82 cu. ft.
