OPERATING INSTRUCTIONS
2. Use a non-slip step with sufficient strength, width (sufficient for wheels not coming off), length (four time higher than the height of loading platform), and hook. Hang the hook of step straight against the loading platform according to the gap with tread of tires of tractor.
HOW TO TRANSPORT TRACTOR WARNING Load and unload with presence and induction of assistant. Keep the tractor clear of children and people. Use a non-slip step with sufficient strength, width (sufficient for wheels not coming off), length (four time higher than the height of loading platform), and hook. Load and unload in flat place where the step does not incline by the weight of tractor. Hang the hook of step straight against the loading platform so that there is no gap with the loading platform and it does not scoot down. Do not change the driving direction on steps. Keep the tractor moving in the center of the steps. Serious accident and personal injury may occure by falling from the steps if the operator fails to do so. If the tractor requires to change the driving direction on steps, unload the tractor from the steps and adjust the direction. Do not use the main shift lever, clutch pedal, differential lock, and single brake during loading and unloading to the vehicle. The tractor may suddenly turn or fall. Load in reverse and unload in forward at low speed. Also, do not operate the steering wheel unnecessarily. When transporting the tractor on the track, apply parking brake and fix it with ropes.
Specifications for step Length
Four times higher or more than the height of the loading platform of vehicle
Width
More than 23.6 in {60cm}
Quantity 2 Strength
1 step is resistant enough for weight over 3308 lbf {1,500 kg}
IGHT
IME
HE S OF
STEP
4T VER
HEIGHT
O
3. Lock the both brake pedals together. [BRAKE LOCKED]
BRAKE PEDAL LOCK
1. Use a vehicle which does not exceed its laden weight and is the sufficient size for not sticking out a part of the tractor when a tractor is loaded. Stop the engine of the vehicle, set the gear shift to “1” or “Reverse”, apply parking brake, and place a wheel chock.
BRAKE PEDAL (LEFT) BRAKE PEDAL (RIGHT) 4. Make sure that differential lock is unlocked.
40
