Instrument Cluster Battery Charging Indicator The indicator will glow if battery is not getting charged. Once the engine is running, this indicator should go OFF if the battery is getting charged. If the indicator glows continuously even when the engine is running above low idle rpm of engine, the cause should be investigated to prevent complete discharge of battery and possible damage of alternator.
High Beam Indicator This indicator (C) glows when Head Lamps are operated in High Beam. Parking Brake Indicator This indicator (G) glows when either brakes or parking brake is applied. Turn Signal Indicators LH and RH turn signal indicators (A & F) are provided to indicate the direction of turning. A blinking LH turn signal indicator (A) implies that the LH Turn Signal of tractor is ON whereas a blinking RH turn indicator (F) implies that the RH Turn Signal indicator of tractor is ON.
A
F
B
G
C
H
Heater Indicator It glows for 60 seconds when key is in "ACC" position and would be activated from ECU only when the engine runs at a higher idle rpm (1200 rpm) until coolant temperature reaches to 20ºC (68ºF) from 0ºC.
D
I
E
J
Air Filter Clog Indicator This indicator (B) is ON when Air filter requires cleaning. Water In Fuel Indicator This indicator (D) should be "ON" for 2 seconds when ignition switch is turned to second position. This indicator will remain "ON" if the water level in the Fuel Filter needs to be drained. The indicator will go "OFF" after draining water from Fuel Filter. CHK ENG (Check Engine) Indicator This indicator (E) will glow when the starter switch is turned to "ON" position. This indicator shall turn-off after engine is CRANKED. A malfunction other than Emission, such as Sensor failures would be indicated by a continuously "GLOWING" or "BLINKING" Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. Non functional 4WD Indicator (H) Not applicable for 2WD model. 32
MIL (Malfunction) Indicator This indicator (J) will glow when the starter switch is turned to "ON" position. This indicator shall turn-off after engine is CRANKED. A malfunction in the electronic emission control system (ECU) is indicated by a continuously "GLOWING" or "BLINKING" Indicator, even past CRANKING of the engine. In such an event, get the problem rectified by an authorized Mahindra Dealer. 4565 2WD TIER-4
