Controls Seat The operator seat can be adjusted for position, tilt and weight of operator. These adjustments are to be done prior to starting the engine. Adjusting Seat Position
A
1. Sit on the operator seat. 2. Push the lever (A) towards RH side. 3. Slide seat forward or rearward to desired position. 4. Release Lever to lock seat in position. Ensure that all controls can be accessed easily. Weight Adjustment To achieve optimum seat suspension, turn the knob (B) till the weight indicator registers your approximate weight on indicator (C). Seat Belt
B
The seat belt is an essential safety feature. To fasten it, pull the belt-end across the lap, and install it in the buckle on the opposite side. A click will be heard when the buckle locks itself. To release the seat belt, press the red button on the buckle. The belt will retract on its own.
Do not use seat belt if operating without a ROPS or with an optional folding ROPS in the folded position. Attempting to adjust the seat while driving the tractor may cause the operator to lose control of the tractor. Always ensure that the tractor is absolutely stationary while making any adjustment of seat.
C
Attempting to adjust the seat while driving the tractor may cause the operator to lose control of the tractor.
Cold Starting Aid A heater element (D) is provided in engine’s intake manifold. When the Key is turned to “ON” position, the element is activated. Heater indicator indicates the activation. The element continues to heat the air in the intake manifold for 42 seconds. A timer controls this time. 1. Turn the Key to “ON” position and hold it till the heater indicator is put-off.
D
2. Crank the engine when the heater indicator light is putoff after 42 seconds.
Note : It is normal for the engine to be louder and have bluish-white exhaust smoke during engine warm-up. The amount of smoke depends on the temperature of air entering the engine. 30
25 Series 2WD, Model - 3825 / 4025 / 4525
