6. TRANSPORTING BACKHOE 6.1. Transporting Backhoe on Tractor CAUTION: To avoid possible injury, observe the following safety rules: 1. Always install transport locking pins into transport position. Refer to page 46. 2. Travel slowly over rough terrain, on hillsides, and around curves to prevent tipping. 3. Do not drive the tractor near the edge of a ditch or excavation. 4. Use accessory lights and SMV emblem when traveling on highways. IMPORTANT: To prevent serious damage to the tractor, read and follow the instructions on decal shown at right: 6.1.1. Before leaving backhoe operator's seat, position the backhoe for transport by raising boom assembly, crowding dipper assembly in, swinging to center and raising the stabilizers. IMPORTANT: When transporting for long distances, periodically examine the backhoe and raise stabilizers and bucket back up to the full transport height. It is normal for the backhoe to slowly settle while being transported.
6.2. Transporting Backhoe and Tractor on Truck or Trailer CAUTION: Do not attach hold down chains to backhoe in order to secure tractor to trailer. Block and secure tractor only. Bucket should be lowered to bed when possible.
Lower backhoe so bucket rests on trailer bed.
6.3. Transport Locking Pins CAUTION: Always install transport locking pins into transport position when transporting or storing unit. This will prevent accidental movement of unit.
45
