INSTALLATION INSTRUCTIONS FOR BACKHOE MODEL 1710C 15.54” Outside to Outside
1710C 10.77” 4.72
1710 CTractor Models 2015 and 2216: Remove Tool Box and Slow Moving Vehicle Sign Bracket.
4.2.9. 1710C on these tractor models 2015 and 2216: Remove the following equipment from tractor: ¾ Remove belly mower (if so equipped) to allow backhoe to be installed. ¾ Park front end loader (if so equipped) during backhoe installation. ¾ Loader Rear Ballast. ¾ Drawbar and Drawbar Bracket. ¾ Slow Moving Vehicle Sign. ¾ All 3-Point components. ¾ Tool Box. ¾ Slow Moving Vehicle Sign Bracket. Note: When backhoe attachment is parked from tractor, reinstall loader rear ballast, drawbar, Slow Moving Vehicle Sign, and 3-point upper, lower links and tool box to tractor before operating.
Remove Slow Moving Vehicle Sign, All 3-Point Components, Drawbar, Loader Rear Ballast, and Drawbar Bracket.
24
