INSTRUMENTS/CONTROLS
SYSTEMS DISPLAY AND CONTROL PANEL 4
6
5
1
2
3
BD00J056
!
WARNING: The display panel indicates the machine’s condition and alerts the operator quickly of any abnormalities by means of lamps indicators or buzzers.
TRIM THIS EDGE
NOTE: Clean the display panel with a soft, dry cloth. Do not use solvents. 1. TRAVEL SPEED SELECTOR - This is a push button for changing from high speed to low speed . A confirmation message appears on the indicator (4).
!
WARNING: All changes in travel speed should be made while the machine is stopped. Always stop the machine to make a shift change.
Low speed : Select this speed to travel on slopes, rough ground or soft terrain. 210 LX and 240 LX , 0 to 2.1 mph (3.3 km/h) High speed : Select this speed to travel on hard, flat ground in good terrain conditions. 210 LX and 240 LX , 0 to 3.4 mph (5.5 km/hr) NOTE: When starting the engine, low speed is automatically selected. NOTE: When the hydraulic system is overloaded and the machine is in High speed, the machine automatically shifts down to Low speed. The system automatically returns to High speed as soon as the hydraulic system is no longer overloaded. 2. WORK MODE SELECTOR - This push button allows one of three working modes to be selected. “S” (standard) mode for ordinary duties; “H” (heavy) mode for hard work or when there is an increase in work load and “L” (lift) mode for precision work requiring lower operating speed. Confirmation of the mode selected is displayed on the indicator (5). NOTE: The selector will not function when “Auto” mode (3) is selected. NOTE: When starting the engine, “H” (Heavy) mode is automatically selected.
48
