LUBRICATION
ENGINE Service specifications Engine oil level check................................................. Every 10 hours or every day Oil change ..................................................................................... Every 500 hours Oil filters replacement ................................................................... Every 500 hours Oil type ..........................................................................See “Fluids and lubricants” Oil capacity....................................................................................24 litres (6.3 gal)
Level
STEP 3
STEP 1
B
Park the machine on flat, horizontal ground. Stop the engine and remove the starter switch key.
A
CS98M579
CD00E091
When the engine has been stopped for fifteen minutes, remove the dipstick, wipe it with a clean cloth and replace it in the guide tube as far as it will go. Then take it out again.
CD00E091
If the oil level is below the mark (A) (minimum), remove the oil filler cap, add oil up to the mark (B) (maximum) on the dipstick and then replace the oil filler cap. NOTE: The level should not be higher than the mark (B) (maximum) on the dipstick.
137
TRIM THIS EDGE RIGHT PAGE Bur 6-25610
TRIM THIS EDGE
STEP 2
