AUXILIARY HYDRAULIC (optional) Your machine has two types of auxiliary hydraulic circuits. One circuit is for single flow equipment, such as hydraulic breakers. The second circuit is for single flow or double flow continuous flow equipment, or double flow equipment such as crushers. Consult your authorized LBX Link-Belt distributor for instructions on how to select the correct pressure for the optional tool.
Hydraulic breaker configuration STEP 1
STEP 3
TRIM THIS EDGE
A24690
CD00E072
Using a hexagonal wrench, place the supply valves in “O” (open) position. See “Optional tool supply valves” in the “Controls/Instruments/Accessories” Section.
Tilt the control on the left-hand arm to the right for hydraulic breaker operation. STEP 4
STEP 2
1
CD00E012
Use the control pedal to operate the hydraulic breaker.
CD00E070
Remove the screw (1), place the flow selector valve in position (B) and then install the screw (1).
