Control and operation
Operating manual
Operating and control elements
A screen appears with the operating hours and the duration for the ten first and the ten last occurrences of the selected error. Press the Back key: the first page of the sub-menu appears. Press the Back key again, to select another error type, or press the Down or Up arrow key, to preselect another error code. The asterisk "*" shows that the error was also indicated by the buzzer and then acknowledged using the Back key. . – s*: signals that the duration is given in seconds. – m*: signals that the duration is given in minutes. Notice! Only operating faults with an error code E 5xx are displayed in the list Exxx menu.
Press the Back key. The first page of the sub-menu appears. Press the Down or Up key to select a new error code or press the Back key again to select another error type . "list E-elec.": Errors of the electrical system
Fig. 3-29
List of the electrical errors
Select "list E-elec.". Press the Menu key: the sub-menu is entered. The screen displays the list of all electrical errors with their error code. The “Test” column displays the number of errors which have occurred since the last deletion. The hour information "reset test at x Hrs" (e g. 12 Hrs) indicates the operating hour in which the "Test" column was the last time deleted. Press the Back key to return to the first page of the sub-menu. Press the Down key and then the Menu key to confirm the new choice.
copyright by
3 - 36
MJFCIFSS
R 974 C / 10069856
