Control and operation
Operating manual
Operating and control elements
Fig. 3-14 1
Main screen, the choosen option is displayed
Denomination of the active option
2
The symbol "R" indicates that an external flow limitation is active
Note! The standard denominations of the options are "Option 1", "Option 2"... The Liebherr after sales department can assign a more concrete name to each option, for example "HM2000" or "Grapple", ...
Menu "Info-hours" - operating hours of components, duration of processes, .. In this menu the screens 1/... to 3/... provide an overview of the operating hours of specific components, of duration of processes and operating types.
Fig. 3-15
Menu "Info Hours" operating hours of Diesel engine
The screen 1/... indicates the operating hours for: – Diesel engine in P mode – Diesel engine in E mode – Diesel engine in F mode – Diesel engine in L mode – Diesel engine at maximum RPM – Diesel engine at low idle – Diesel engine with RPM adjustment in manual control Press the Menu key. the screen 2/... is displayed. The screen 2/... provides the operating hours for: – Working attachment movements using the joystick
copyright by
3 - 28
MJFCIFSS
R 974 C / 10069856
