Control, operation
Operating manual
Operating and control elements
The stick cylinder shut-down can be adjusted in various ways, depending on the equipment of the machine: Menu option
Description
teach max
Saving of current stick position as the maximum permissible stock position for retraction of the stick. Move the attachment to its highest position. Carefully retract the stick with the respective attachment (e.g. grapple) to the desired position. Move the cursor to the teach max line and press the RIGHT key to change to the right field. Press the UP button to enter the value "1" and confirm with ENTER. The current stick position (act. position) is stored as the maximum permissible stick position (stl max point). Move the cursor to the >back line and press the RIGHT button. The display shows the subordinate menu.
stl max point
Enter the maximum permissible stock position for retraction of the stick. Position the stick within the planned range of movement. Move the cursor to the stl max point line and press the RIGHT button to change to the right field. Press the UP or DOWN button to select the new value and confirm with ENTER. The maximum permissible stick position for retraction is saved. Move the cursor to the >back line and press the RIGHT button. The display shows the subordinate menu.
teach min
Saving of current stick position as the maximum permissible stock position for extension of the stick *). Carefully retract the stick with the respective attachment (e.g. grapple) to the desired position. Move the cursor to the teach min line and press the RIGHT key to change to the right field. Press the UP button to enter the value "1" and confirm with ENTER. The current stick position (act. position) is stored as the maximum permissible stick position (stl min point). Move the cursor to the >back line and press the RIGHT button. The display shows the subordinate menu.
copyright by
3 - 22
MJFCIFSS
A 316 Litronic Industrie / 11140219
