This menu is used to activate the application of an attachment with hydraulic cylinder (e.g. mower rake). Menu navigation: Use the UP and DOWN keys to select the "cylinder extern" line. Press the RIGHT key. The cursor changes to the right section where you can change the parameter value. Use the UP and DOWN key to select the desired setting. 1 = Use of attachment possible. 0 = Use of attachment not possible. Press the ENTER button. Move the cursor to the >back line and press the RIGHT button. The display shows the superordinate menu.
Hbg max point (optional equipment) In situations where the machine's working space is limited in the vertical direction (e.g. by power transmission lines), it may be helpful to use stroke limitation to predefine a max. working height. Danger! Risk of injury and damage to equipment! During the adjustment of the stroke limitation, there is a risk of serious damage and injury, as the equipment might collide with another object. When adjusting the limitation function, operate the machine with exceptional care. Setting stroke limitation:
Fig. 3-15
Attachment at max. working height - example:
1
Obstacle (e.g. tunnel roof, overhead power line)
2
Safety margin, as prescribed
m Max. working height (shut-off point)
The maximum permissible working height m must be at a sufficient distance to the object 1 that limits the vertical movement of the machine. For the adjustment of the shut-off point, the machine must be properly supported. The settings are shown at the display in the hbg max point submenu:
