Control, operation
Operating manual
Operating and control elements
S93 - Heating This rotary switch is used to adjust the temperature of the blower air. S284 - Blower output The blower has 4 output levels. The rotary switch is used to adjust the blower output.
S318 - A/c system* During a/c operation, the blower air is cooled. The cooling effect can be adjusted with the heating S93. The cooling effect is greatest when the heating is switched off (rotary switch S93). S398 - Switching of blower air output The switch determines whether the air flow of the blower exists at the rear panel of the cab or in the legroom. Within the legroom, the air distribution can be further adjusted (see S92).
* optional equipment
3.1.3.3
Control console C
Fig. 3-5
Control console C
S8 - Beacon* Activates the beacon.
copyright by
3-6
MJFCIFSS
A 316 Litronic Industrie / 11140219
