Control, operation
Operating manual
Operating and control elements
S21 – Creeper gear The creeper gear allows for precisely controlled travel of the machine at low speeds and improves the travel behaviour of the machine on slopes and in difficult terrain. The creeper gear may only be selected when the machine is standing still. The creeper gear may only be selected when the machine is standing still. S42 – First gear The transmission can be operated at two speeds. The first gear is selected with the switch. If the switch is not actuated, the machine is automatically operated in second gear. S47 - Hydraulic quick-change adapter* Activates the hydraulic quick-change adapter for the attachment and removal of tool attachments. The quick-change adapter can be locked and released.
S204, S205, S206, S207 - Individual outrigger control* Activates the outrigger control system. Each outrigger can be operated individually or together with the other outriggers. When the joystick is moved, the activated outriggers are moved. S241 - Additional user* This switch determines whether the attachments (additional consumers) or the boom adjustment (if mounted) can be operated. Depending on the switch position (see chapter "Tool Control"), the consumer is supplied with hydraulic oil at adjusted pressure and flow settings. S335 - Blade support / dozer blade Activates the blade support. When the joystick is moved, the blade or dozer blade is operated.
S360 - Acknowledgement of quick change adapter buzzer** Switches off the acoustic warning signal of the quick-change adapter. A warning signal indicates that the quick-change adapter is not properly locked. If no other tool attachment is to be mounted, it is useful to switch off the warning signal. This is also recommended to ensure that other buzzer sounds (i.e. from the overload warning system) are actually audible. S363 - Tempomat* The Tempomat allows you to save the current drive pedal position. This means that the travel speed is maintained even if the foot is lifted from the pedal.
S422 - Radio mute mode The radio mute mode allows you to reduce the volume of the radio to mute level without switching off the radio.
* optional equipment
copyright by
3-4
MJFCIFSS
A 316 Litronic Industrie / 11140219
