Control, operation
Operating manual
Parking and exiting machine
3.7 Parking and exiting machine
Fig. 3-119 Parking 1 S16
Brake pedal (operating brake) Switch / parking brake
S263 Travel direction switch
Before exiting the machine, apply the parking brake and release the operating brake. Set the travel direction switch S263 to its neutral position 0. Move the safety lever up. The parking brake S16 is applied. Switch off the diesel engine. To release the operating brake 1: Release the retainer (see arrow), using your foot.
3.8 Transport 3.8.1
Safety instructions – Insure that the transporting vehicle or truck trailer is rated for the intended machine weight and size. – Park the machine on a level surface and chock the track chains and/or wheels. – During transport, remove parts of the attachment that create an over width or length condition, if necessary. – Clean the undercarriage. The undercarriage must be swept clean, meaning, the chains / wheels must be free of snow, ice and sludge prior to driving onto the transporting vehicle. – Align the machine precisely with the loading ramp. – Attach the manual lever for sensitive driving (crawler excavator) to the driving pedals. – Have another person guide and signal the operator.
