Control, operation
Operating manual
General working methods
Fig. 3-112 Permissible working range for hydraulic cylinders
3.6.2
1
Possible swivel range
2
Permissible working range with 10 ° distance to end position
3 5
Limit range Hydraulic cylinder
4
Boom or stick
Preparation
Fig. 3-113 Safe working: observe machine range and danger zones Danger! Risk to life and limb when the machine is swivelled. Ensure that no persons are standing inside the danger area r of the machine.
