Control, operation
Operating manual
Working with the machine
Press the switch S216. The indicator light in the switch is on. The stick cylinder shut-off function is overridden. The buzzer (warning signal) sounds. For the next 10 seconds, the stick can be moved across the limits of the shutoff function. Display:
Carefully move the stick beyond the shut-off point into the danger range. The buzzer is automatically switched off as soon as the stick is again within the permissible working range. The stick cylinder shut-off function is automatically reactivated after 10 seconds. Press the switch S216 again, – to move the attachment back to the permissible operating range – after the 10-second period has lapsed
3.4.17.4
Adjusting the stick cylinder shut-off function Adjust the settings according to the respective equipment: 1. Mechanical stick cylinder shut-off function 2. Electronic stick cylinder shut-off function
1. Adjusting mechanical stick shut-off function
Fig. 3-83
Shut-off point
Move the elevating operator's cab (optional equipment) to its most forward extended position (see Fig. 3-83). Move the attachment (boom) to its highest position. Carefully retract the stick with the respective attachment (e.g. grapple) to the desired position.
copyright by
3 - 82
MJFCIFSS
A 316 Litronic Industrie / 11140219
