Control, operation
Operating manual
Working with the machine
Use this menu to activate the pedals for boom adjustment while an attachment (e.g. mower rake) is operated. Setting values: For a description, see chapter "Operator's menu", submenu "Y268 on/off".
3.4.12
Operating attachment tool (mini joystick control, optional equipment) Danger! The working attachment can cause serious or even fatal injury to persons. Ensure that no persons are standing inside the danger zone of the machine. It is strictly forbidden to guide the attachment tool by hand.
Danger! If a large or wide attachment tool (e.g. grapple) is swivelled towards the operator's cab, it might collide with the cab or even break through it, causing danger to the machine operator. Always keep a safe distance between the moving attachment tool and the operator's cab.
3.4.12.1
Working functions
Fig. 3-77
Mini joystick, operating attachment tool
The working functions of the attachment tool are controlled by means of a mini joystick located on the right joystick. The further the mini joystick is moved in a particular direction, the faster the attachment tool is moved. In this control mode, it is not necessary to activate the attachment tool with a separate switch as these functions are automatically activated when the servo control is switched on.
copyright by
3 - 74
MJFCIFSS
A 316 Litronic Industrie / 11140219
