Control, operation
Operating manual
Working with the machine
In the event of an emergency, the attachment can be lowered even if the diesel engine is not running. Turn the ignition key to contact position 1. Operate the joysticks or pedals until the attachment is fully lowered. Note The attachment is lowered with the residual pressure in the control oil unit. This reserve is however limited and allows only for a limited number of operations of the pilot control units. Therefore only use the joysticks to lower the attachment and do not attempt to complete other movements.
3.4.6
Swivelling uppercarriage Caution! All machines are equipped with the PCSA control as standard. On special request, the machine can be fitted with a different control system (e.g. LIEBHERR control). For such machines, observe the instructions in the respective separate operating manual. The joystick functions described here apply only to the PCSA control. The uppercarriage is swivelled by means of the left joystick.
Fig. 3-69
Swivelling uppercarriage
Move the joystick to the left c. The uppercarriage is swivelled to the left. Move the joystick to the right d. The uppercarriage is swivelled to the right. If required, also adjust the sensitivity of the slewing gear (see chapter "Display", Torque Slew menu):
copyright by
3 - 68
MJFCIFSS
A 316 Litronic Industrie / 11140219
