SECTION 6 - HYDRAULIC FIGURE 6-9. HYDRAULIC DIAGRAM LIST

ITEM

PART NUMBER

2791592 2791957

Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref Ref

2792002 2791857 2791960 2792003 1281326 2791655

Ref Ref Ref Ref Ref Ref

2791656

Ref

2791657 1281284 2791625

Ref Ref Ref

2791624 2791866 2791865 1281328 2791645 2791677 1281327 2791627 2791678 1281547 2791803 2791804 1281330 2791660 2791682 1281329 2791632 2791680 1281548 2791805 2791807 0251299 0253239 2791785 2791968 0253393 2791578

206

QTY Ref

DESCRIPTION Note: Information on diagrams not shown is available from JLG Service/Parts Departments. Axle Lockout Hydraulic Diagrams: All Machines Built Prior to June 1992 2WD Machines Built June 1992 to Present 4WD Machines Built June 1992 to Present Drive Hydraulic Diagram - 2WD/2WS Without Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Drive Hydraulic Diagram - 2WD/2WS With Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Drive Hydraulic Diagram - 2WS/4WS With Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Drive Hydraulic Diagram - 4WD/2WS Without Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Drive Hydraulic Diagram - 4WD/2WS With Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Drive Hydraulic Diagram - 4WD/4WS With Swivel: Deutz With Standard Bang-Bang Controls Deutz With Proportional Controls Manual Descent Hydraulic Diagrams: Valves and Hosing (Prior to June 1992) Valves and Hosing (June 1992 to Present) Hydraulic Diagram (Prior to June 1992) Hydraulic Diagram (June 1992 to Present) Oil Cooler Hydraulic Diagram Rotate Hydraulic Diagrams: Standard Bang-Bang and Proportional Controls Standard Hydraulic Diagrams: Deutz With Standard Bang-Bang Controls (Prior to June 1992) Deutz With Standard Bang-Bang Controls (June 1992 to May 1993) Deutz With Standard Bang-Bang Controls (May 1993 to Present) Deutz With Proportional Controls (Prior to June 1992) Deutz With Proportional Controls (June 1992 to May 1993) Deutz With Proportional Controls (May 1993 to Present) Steer Hydraulic Diagram Without Swivel (2WS) 2WD Fixed Axle With Standard Bang-Bang or Proportional Controls 2WD Oscillating Axle With Standard Bang-Bang or Proportional Controls 4WD With Standard Bang-Bang or Proportional Controls Steer Hydraulic Diagram With Swivel (2WS) 2WD Fixed Axle With Standard Bang-Bang or Proportional Control

40HA

REV

3120805
