Digital Control Panel Operation Manual
Version 1.0
Circuit Breaker Status The status of both the Generator Circuit Breaker and the Mains Circuit Breaker are viewable on the JCB Digital Control Panel;
Circuit Breaker Closed
Circuit Breaker Open
Automatic Mode NOTE In an Installation where remote starting is required, either through the ATP7 operation mode or in standard mode with 2wire remote start enabled the Generating set should be left in AUTO mode at all times unless manual control is required, this will enable the generating set to startup and assume load upon receiving the external start signal. Failure to do so will result in unit not starting when required.
The Generating set will behave slightly differently in automatic mode depending on whether it is setup for ‘Standard Operation’ or ‘ATP7 Operation’. To put the soft key. Genset into AUTO mode, from the top level screen press the Enter AUTO Mode
)
In AUTO mode the JCB Digital Control Panel will control all START / STOP and other functions depending on the system configuration.
Page 9 of 25
