Digital Control Panel Operation Manual
Version 1.0
Information Screens The JCB Digital Control Panel can be used to display information about the status of the engine, alternator and complete generation system. Depending on the application the JCB Digital Control Panel has a varying number of information ‘screens’. To access these screens use the scroll button as follows. NOTE While scrolling Information screens user can scroll up (to access previous screen) as well as down (Accessing the next screen). Additional features are accessible in some of the screens, indicated by icons beside the soft keys.
Top Level Screen The sub menu, information screens are accessed through scrolling from the top level screen. Top level screen provides an overview of the generating set and is the starting point for accessing other information screens.
) ¾ Mains Overview Screen (only when enabled) This screen provides the mains voltage information; user can change the method of voltage measurement for the mains reading see ‘Changing method of voltage calculations’, also displayed are mains frequency, kW and phase current.
) ¾
) ½
Generating Set Overview Screen All parameters monitored from the Genset are displayed here. Generator voltages line-line and line-neutral; generator currents for each phase; generator frequency; generator real/reactive power, power factor and engine RPM.
) ¾ Page 12 of 25
) ½
)
Return to ‘Top Level’
