Preparation for Work
Preparation before use ■ Adjusting the Forward/Backward Position of the Seat The seat can be adjusted forward and backward according to the body size of operator. Adjust the seat to a suitable position so that the levers and pedals can be operated properly.
1. Tilt the seat forward and loosen the knob bolts (2 pcs) under the seat, or adjust the seat base forward or backward. Seat Knob Bolt
2. Sit on the seat and confirm that you can operate the levers and pedals properly.
Seat Base
3. Tilt the seat forward and securely tighten the knob bolts (2 pcs) under the seat to lock the seat base.
■ Adjusting the Steering Wheel Height The height of the steering wheel can be adjusted at one of three different positions according to the body size of the operator. Adjust the height at a position where the steering wheel can be operated properly.
1. Remove the bolt and U-nut before moving the handle shaft. 2. Move the handle shaft up and down to adjust the height. 3. A loose handle shaft will bring a very dangerous situation, so securely tighten the bolt and U-nut.
28
Handle shaft
U-nut Bolt
