SCMA54&SCMB48&SCMC48
V. STORAGE OF MOWER DECK When the mower deck is to be stored for a long period, service the deck as mentioned below before storing it. a. Clean the mower deck. Take special care to remove grass and dirt from the blades and underside of the mower deck. b. Remove grass or other objects tangled around the rollers and shafts. c. Remove the belt covers, and clean the mower deck top. Be sure to remove grass and other objects tangled around the pulleys and shaft. d. Check the belt. If the belt is normal, loosen the tension pulley. e. Remove all rust and touch up where paint has been peeled off with touch-up paint supplied by ISEKI. f. Be sure to re-install all the removed parts. g. Lost pins and clips should be re-install with new ones. h. Check each part for damage and repair or replace damaged ones with new ones for the next operation. IMPORTANT: Use ISEKI genuine parts when replacing. i. Grease up all grease points. j. All loose bolts and nuts should be tightened properly and lost ones should be re-install with new ones. k. Store the mower deck in a dry place with wooden blocks placed under it and cover with tarpaulin or the like. CAUTION: When storing with the mower deck installed on the lawn mower, be sure to lower it on ground to prevent unexpected accidents caused by manipulation of the lift lever by children or unauthorised people.
90
