SCMA54&SCMB48&SCMC48
II. ATTACHING AND DETACHING MOWER DECK WARNING: When attaching or detaching the mower deck to the lawn mower: • Place the lawn mower on level, hard ground. • Apply the parking brake securely. (GE TYPE) • Apply the parking lock securely. (E TYPE) • Move the PTO lever to the STOP ( ) position. • Do not start the engine except for operating the lift. 1. ATTACHING THE MOWER DECK Attach the mower deck first to the lawn mower and then connect the drive shaft.
1
9
10
7
6
(1) Lift lever (2) Lower chute (3) Gauge wheel
8
11
(4) Ring clip (5) Rear link (6) Drive shaft
5
3
4
(7) Front link (10) PTO cover (8) Lock nut (11) Joint cover (9) Height adjustment dial
76
2
