SXG326 & SXG323 18. REPLACEMENT OF ENGINE OIL FILTER
The transmission oil drain is located under the centre of transmission case.
IMPORTANT: • The engine oil filter should be replaced after the initial 50 hours of operation and then after every 300 hours of operation. • It is recommended to ask your dealer to replace the engine oil filter, because this operation requires a special tool. But when there is no alternative but to replace the filter by yourself, observe following instructions. a. Drain engine oil completely following the instructions of “17. REPLACEMENT OF ENGINE OIL .” b. Place some rags under the engine oil filter to receive dripping oil when the filter is replaced. The engine oil filter is located on the Left-hand wall of the cylinder block.
(1) Drain plug a. Place a tray under the drain plug. b. Remove the drain plug and let the oil drain out. c. Reinstall the drain plug and tighten it securely. d. Pour new transmission oil through the oil filler (Refer to page 50) on top of the transmission case until the level reaches the upper limit on the level gauge (dipstick). Transmission oil capacity
Type H-U
8 liters (1.76 imp.gal.)
e. After replacing engine oil, start the engine and let it idle for a while. Then stop it and wait for a while until the oil comes down into the oil pan. Now check the oil level to check to see if it is at the upper limit or not. When the level is low, replenish until the level reaches the upper limit.
(1) Engine oil filter c. Loosen the filter using a filter wrench and remove it. d. Install a new filter with the O-ring lubricated with fresh engine oil. Screw in the filter until its packing comes into contact with the sealing surface of the engine and then tighten it by a 2/3 turn with the filter wrench.
f. Make sure that there is no oil leaking through the oil filter, suction filter, rubber hoses, or drain plug. 20. REPLACEMENT OF HYDRAULIC OIL FILTER
e. Pour the drained oil back in referring to “17. REPLACEMENT OF ENGINE OIL.”
IMPORTANT: • The hydraulic oil filter should be replaced after the initial 50 hours of operation and then after every 300 hours of operation. It should also changed every time the transmission oil is replaced. • It is recommended to ask your dealer to replace the hydraulic oil filter. But when there is no alternative but to replace the filter by yourself, observe the following instructions.
19. REPLACEMENT OF TRANSMISSION OIL IMPORTANT: • The transmission oil should be replaced after the initial 50 hours of operation and then after every 300 hours of operation . • It is recommended to ask your dealer to replace the transmission oil, because this operation also requires replacement of the hydraulic oil filter and washing or replacement of the suction filter. But when there is no alternative but to replace the filter by yourself, observe the following instructions. 58
