SXG326 & SXG323 a. Depress the master brake pedal (2) until it stops by stopper (3) and adjust brake rod (5) so that clearance of spring coil (1) is 0.3mm.
IMPORTANT: • When the belt is extremely expanded or has any damage, replace the belt with new one. • Be sure to use the following ISEKI’s genuine belt. SXG326 SXG323
b. Pull up parking lever (7) until the 8 notch and adjust the adjustment cable nut (8) of brake cable (4) so that clearance of spring coil (1) is 0.3mm.
3695-303-003-00....Belt (VB041) ....2pcs. 1728-334-013-00....Belt (VB039) ....2pcs.
c. After adjusting brake rod (5), tighten the lock nut (6) properly.
11. ADJUSTMENT OF MASTER BRAKE PEDAL
12. NEUTRAL POSITION OF HST
(E TYPE)
WARNING: After a long time of use, the neutral position of the HST unit may change, which will cause various troubles such as difficulty in stopping the lawn mower, changing over between forward travel and reverse travel, etc., which is very dangerous. IMPORTANT: • When the HST unit is out of order, ask your dealer to repair it. • The adjustment of the neutral position of the HST unit should be done by your dealer.
(1) Clearance of spring coil (2) Master brake pedal (3) Stopper (4) Brake rod
When there is no alternative but for the user to adjust it, follow the next instructions: The neutral arm of the HST unit is located around the centre under the step. With this arm, the neutral position can be adjusted.
(5) Lock nut (6) Brake assy (7) Parking lock
1
a. Depress the master brake pedal (2) until it stops by stopper (3) and adjust brake rod (4) so that clearance of spring coil (1) is 0.6mm. b. After adjusting brake rod (4), tighten the lock nut (5) properly. (GE TYPE) 2
3
(1) Lawn mower (2) Tire chocks
4
2
(3) Front wheel (4) Rear wheel
a. Place the lawn mower on level, hard ground. Put tire chocks in the positions a little apart from the front wheels and rear wheels as shown in the figure. b. Move the PTO lever to the OFF position (
).
c. Stop the engine and remove key from the starter switch. (1) Clearance of spring coil (2) Master brake pedal (3) Stopper (4) Brake cable (5) Brake rod
(6) Lock nut (7) Parking lever (8) Adjustment cable nut (9) Brake assy 54
d. Apply the parking brake (GE TYPE) or the parking lock (E TYPE). e. Loosen the lock nut of the adjustment rod.
