SXG326 & SXG323 ・Move the lever to 'unload' position as below.
Hook up the rope to the front hitch(opt.). The distance between towing vehicle and mower should be less than 5m. Release the parking brake lock.
Fig.1
7.Jacking When jacking mower, place the mower on level and hard ground which is sufficiently illuminated, otherwise un expected accidents may occur. Follow the instructions listed below: ・Apply parking brakes. ・Disengage all PTO. ・Remove the stater key. ・Place the jack on level. ・Put tire chocks to the rear wheel when jacking up the front wheels. ・Put tire chocks to the front wheels when jacking up. When raising the rear axle, suitable shims, 1, should be wedge between the front axle and the front frame.
1
When raising the front axle, the jacking point is the front hitch or the front axle as Fig.1, For the rear axle, the jacking point is the lower flame of collector as Fig. 2.
48
FIg.2
