SBC600X-3H & SBC550X-3L
V. STORAGE OF COLLECTOR When the collector is to be stored for a long period of time, service the collector as mentioned below before storing it. a. Clean the collector. Take special care to remove grass and dirt from the container net. b. Remove grass or other objects tangled around the linkage and hydraulic hose. c. Remove all rust and touch up where paint has been peeled off with touch-up paint supplied by ISEKI. d. Be sure to re-install all the removed parts. e. Lost pins and clips should be re-install with new ones. f. Check each part for damage and repair or replace damaged ones with new ones for the next operation. IMPORTANT: Use ISEKI genuine parts when replacing. g. Grease up all grease points. h. All loose bolts and nuts should be tightened properly and lost ones should be re-install with new ones. i. Store the collector in a dry place with wooden blocks placed under it and cover with tarpaulin or the like. CAUTION: When storing with the collector installed on the lawn mower, be sure to lower it on ground to prevent unexpected accidents caused by manipulation of the dump lever by children or unauthorised people.
102
