IV. INSPECTION AND MAINTENANCE OF MAJOR PARTS
IV. INSPECTION AND MAINTENANCE OF MAJOR PARTS 1. INSPECTION OF CYLINDER (SBC550X-3L) a. Cylinder can be adjusted its length. b. Adjust the length of cylinder so that its length will be the shortest when the collector is at the lowest position.
(1) Lock nut
(2) Adjustment adapter
CAUTION: Container would be damaged by making length of cylinder too longer. Be careful to adjust its length. 2. INSPECTION OF HYDRAULIC HOSES a. When operating the collector, make sure that the hydraulic hose is not pulled and interfered. b. When the hydraulic hose is damaged, replace it as soon as possible. DANGER: It is danger to operate the lawn mower with damaged hydraulic hose. It may cause that collector falls or hydraulic hose burst suddenly.
99
