V. OPERATING INFORMATION CAB OPERATION CONTINUED
Climate Controls 1
2
ADJUSTING FAN BLOWER SPEED- Fan blower speed is controlled by the left rotary dial on the cab climate control panel (fig. 5.83, item 1). The fan blower speed is a continuously variable adjustment. To increase fan speed, rotate fan blower dial clockwise. To reduce
3
fan
speed,
rotate
fan
blower dial
counterclockwise. To shut fan blower off, rotate fan FIG 5.83
blower dial all the way counterclockwise. ADJUSTING TEMPERATURE SETTING - Forced air temperature adjustments are controlled by the right rotary dial on the cab climate control panel (fig. 5.83, item 2). Temperature control is a continuously variable adjustment. To increase forced air temperature, rotate temperature dial clockwise. To decrease forced air temperature, rotate temperature dial counterclockwise. OPERATING AIR CONDITIONING - To activate the air conditioner, depress the air conditioning switch (fig. 5.83, item 3). Adjust fan speed and temperature
FIG 5.84
accordingly. ADJUSTING VENTS - Air vents may be adjusted by rotating them for desired direction (fig. 5.84) or individually turned on or off with the directional fins (fig. 5.85). SERVICING A/C SYSTEM - See pages 86 and 90 for service information.
FIG 5.85 OPERATING INFORMATION CONTINUED
