V. OPERATING INFORMATION SETTING UP THE HAGIE TASSELTROL®/LS SYSTEM 12™ Initial Set Up
FIG. 5.31
2
ON
AUTO
OFF
MAN.
DEPTH CONTROL
1. Enter the Parameter Mode: Select AUTO by placing the AUTO/ MAN. switch (fig. 5.32, item 1) in the AUTO position. Now turn on the DEPTH CONTROL (fig. 5.31) by placing the ON/OFF switch (fig. 5.32, item 2) in the ON position. In the LCD display window (fig. 5.33), there will
LIFT
LIFT LIFT
LIFT LIFT
LIFT
1
2
4
6
3
5
FIG 5.32
be four lines. The top line displays the program level. The second line will flash SELECT MANUAL as a warning that you are about to enter the parameter adjusting mode. The current parameter settings are displayed on
FIG. 5.33
the bottom line of the window. The values for B, R,
OPERATING INFORMATION CONTINUED
