IV. PREPARING TO OPERATE CUTTER HEADS CONTINUED
Blade Rotation Left of Operator Hydraulic hoses on cutter heads should be hooked up so blades on heads mounted left of operator rotate according to figures 4.19 and 4.20 (counter-clockwise from above). Refer to the Hagie 204SP Parts Manual for corTWO-HEAD SERIES
rect hardware, hose lengths, and hydraulic
nt fro
schematic.
NOTE: Care should be taken when installing check valve (fig. 4.19, item 1) on cutter motor so the flow arrow is oriented correctly (either two-head or three-head series).
IMPORTANT: Case drain hoses must be installed correctly on cutter motors to prevent
1
motor damage. Refer to parts manual. FIG 4.19
nt fro nt fro
THREE-HEAD SERIES
FIG 4.20
31
