Working Range Limiter 1.4 Operating Working Range Limiter
1.4.7
Switching monitoring on and off
Switching monitoring on
G H
After the ignition is switched on, all monitoring functions are switched on that were on before the ignition was switched off. Danger of accident due to erroneously set limit values! If, during starting operations or after entering new limit values, you switch on the monitoring, then make sure that the settings for the limit values are correct. Start up the limit value slowly and check whether the movement has been switched off at the right time. If necessary, enter new values with a larger safety distance. After switching on the monitoring, all of the driving gears' speeds are limited to a maximum of 50 %. This is also valid for the driving gear where higher values are set in the submenu Driving gear speeds. Limits under 50 % continue to be active. A limit between 30 and 50 % is recommended for the slewing gear speed.
The monitoring is switched on with the buttons under symbols (4) to (7). When the monitoring is switched off, the background to the corresponding symbols is black.
• Press the button under the desired symbol once (e.g. under symbol (6) for monitoring the slewing angle). The background to the symbol is now yellow and the monitoring is switched on. Those limiting values are monitored that are entered in displays (1) to (3) Read entered limiting values, p. 1 - 8). (
à
05.02.2001
s
Operating instructions Working Range Limiter
2 084 658 en
1 - 19
