Working Range Limiter 1.4 Operating Working Range Limiter
1.4.6
Entering limiting values manually If you know the values for the switching points, you can also enter these values manually.
Limiting values for total height, working radius or slewing angle
In all entry menus is the symbol Manual entry on/off. After the menu in opened, manual entry is always switched off.
• To switch manual entry on and off press the button under the Manual entry on/off switch (1). After pressing the button, the background colour of the symbol changes: Background yellow:
Manual entry on
Background black:
Manual entry off
• Select the display for entry (e.g. the Maximum/current total height display, 1).
• Switch on the manual entry. The continuous display of this value is then switched off and the Entry rotary switch (2) is active. You can now enter the value surrounded in blue directly into the selected display (1). The continuous display of this value is now switched off.
• Press the Confirm entry button once (Ö) to adopt the value as a limiting value.
In display (1), the upper value (surrounded in red) now shows the newly set limiting value.
• Switch off the manual entry. In display (1), the lower value (surrounded in blue) now continuously shows the value for the current position of the boom position and the superstructure.
