Working Range Limiter 1.4 Operating Working Range Limiter
1.4.5
Enter point data for objects This section presupposes that the parameters for the point data of the objects are unknown and therefore describes the input by starting the switching points. For this, the following prerequisites must be fulfilled:
à
Entering limiting values manually, p. 1 - 17, – manual entry is switched off; – monitoring of objects, working radius and slewing angle are all switched Switching monitoring off, p. 1 - 20. off;
à
H H
When the monitoring functions are switched on, the required crane movements for starting individual points can be switched off. If manual entry is switched on, you cannot adopt the values for the currently started switching point. You can cancel the following entry at any time by pressing the Exit submenu/ entry mode ( ) button once. The red bar under the selected entry goes out.
ö
• Press the button near the symbol Point data for objects entry submenu (1) once. The Point data for objects entry submenu opens.
Presentation of defined objects
The Point data for objects entry submenu opens. All entered points are presented pictorially in the Limitation by object display. All entered points are represented by a cross and numeration in the Limitation by object display (e.g. point 1). Points that are connected to one object are fastened with lines (e.g. points 1 to 3 and points 5 and 6). The pictorial presentation corresponds to the values in the Point data display (7). Every point is defined by two values: – by the angle for positioning the superstructure and
The current boom position is always represented by a cross (8) and by the values (surrounded in blue) in display (7).
1 - 14
2 084 658 en
Operating instructions Working Range Limiter
05.02.2001
– by the working radius.
