Working Range Limiter 1.4 Operating Working Range Limiter
Read entered limiting values
H
You can check in the Working Range Limiter submenu which limiting values are entered for the individual monitoring functions. All illustrations in these operating instructions use metric measuring units. Depending on the country in which you are working, the display can also be in US units of measurement; conversion is carried out at the factory. The displays 1 Maximum/Current total height 2 Maximum/Current working radius 3 Maximum/Current slewing angle show you both the maximum set value and the current value. – The values surrounded in red (displays (1) and (2) upper value, display (3) upper and lower value) always show the maximum set position. – The values surrounded in blue (displays (1) and (2) lower value, display (3) middle value) always show the values that correspond to the momentary position of the boom and the superstructure (current value).
H
The displays surrounded in blue only show the current value if the manual entry is switched off. When the manual entry is switched off, the value can be changed in the display as desired; Entering limiting values manually, p. 1 - 17.
à
The values for the point data of individual objects can only be read for obEnter point data for objects, jects in the Point data entryfor objects submenu; p. 1 - 14.
05.02.2001
à
1-8
2 084 658 en
Operating instructions Working Range Limiter
