TMS800E OPERATOR’S MANUAL 6.
SET-UP AND INSTALLATION
Remove retainer clip (1, Figure 4-15) from the pin attaching the 7m (23 ft) section to the base section.
.
10. Use the controller to pivot the boom extension so that lugs (1, Figure 4-18) on boom extension align with the holes in the lugs (2) on the boom nose.
2
1
1
6642-5
FIGURE 4-15 FIGURE 4-18
6642-11
7.
Remove the stowage pin (1,Figure 4-16).
11. Remove pins (1, Figure 4-19) stowed in extension and install in holes (right side of boom nose) and secure with retainer clips (2).
1
1
6642-6
4
FIGURE 4-16 2
8.
6642-13
Stow the pin (1, Figure 4-17) in pin holder (2) provided on the swingaway extension.
FIGURE 4-19 12. Remove the clip pin (1, Figure 4-20) from the stowage pin (2) at the front mount. Unpin the stowage pin (2) and store in holder (3).
2 2 3 1
6642-7
1
9.
FIGURE 4-17
Remove the jib stowage controller from behind the seat in the superstructure cab.
GROVE
6642-46
Published 12-22-2008, Control # 107-09
FIGURE 4-20
4-13
