TMS800E OPERATOR’S MANUAL
OPERATING CONTROLS AND PROCEDURES
3.
Apply parking brakes and if necessary, chock the wheels.
4.
Position all controls to neutral or off.
5.
Shut down the engine using the proper procedures as specified by this Handbook and the engine manual.
6.
Perform any other specified procedures required at the end of the workday, i.e., drain water from the fuel filter water separator, refueling, etc.
DANGER
7.
Close all windows.
8.
Remove the keys from the crane.
9.
Lock the crane. Install vandal guards, if used.
Step 10 does not take the place of the prestarting checks which must be performed just prior to using the crane at the next working day. 10. Make a thorough walk around inspection to ensure that all cylinders that can be retracted are retracted. The only exceptions are those cylinders which cannot be fully retracted, i.e., steer cylinders. Also, look for anything that could hinder or prevent starting the next day’s work.
3
GROVE
Published 12-22-2008, Control # 107-09
3-39
